Connecting Your VS-88HD 8x8 SD/HD-SDI Matrix Switcher

6.4 Genlock Switching

The following Genlock switching procedures apply to firmware version 2.2

and higher.
The

VS-88HD performs switching during the vertical interval according to

the RP168 standard when the Genlock signal is connected with the following

set up:

For NTSC, press and hold the input 7 button for few seconds (the LCD

will flash)

For PAL, press and hold the input 8 button for few seconds (the LCD will

flash)

For 1080i@60Hz, press and hold the input 1 button for few seconds (the

LCD will flash)

For 1080i@50Hz, press and hold the input 2 button for few seconds (the

LCD will flash)

For 720p@60Hz, press and hold the input 3 button for few seconds (the

LCD will flash)

Note that last set up is saved in the non-volatile memory
