VS-88FO - Kramer Protocol 2000 39
INSTRUCTION DEFINITION FOR SPECIFIC INSTRUCTION NOTE
# DESCRIPTION INPUT OUTPUT
0 RESET DEVICE 0 0 1
1 SWITCH VIDEO Set equal to video input which is to
be switched
(0 = disconnect)
Set equal to video output which is
to be switched
(0 = to all the outputs)
2, 15
3 STORE VIDEO
STATUS
Set as SETUP # 0 - to store
1 - to delete 2, 3, 15
4 RECALL VIDEO
STATUS
Set as SETUP # 0 2, 3, 15
5 REQUEST STATUS
OF A VIDEO OUTPUT
Set as SETUP # Equal to output number whose
status is required
4, 3
15 REQUEST WHETHER
SETUP IS DEFINED /
VALID INPUT IS
DETECTED
SETUP #
or
Input #
0 - for checking if setup is defined
1 - for checking if input is valid 8
16 ERROR / BUSY For invalid / valid input (i.e.
OUTPUT byte = 4 or OUTPUT byte
= 5),
this byte is set as the input #
0 - error
1 - invalid instruction
2 - out of range
3 - machine busy
4 - invalid input
5 - valid input 9, 25
30 LOCK FRONT PANEL 0 - Panel unlocked
1 - Panel locked 0 2
31 REQUEST WHETHER
PANEL IS LOCKED
0 0 16
56 CHANGE TO ASCII 0 3 – Protocol 3000l 19
61 IDENTIFY MACHINE 1 - video machine name
3 - video software version
0 - Request first 4 digits
1 - Request first suffix
13
62 DEFINE MACHINE 1 - number of inputs
2 - number of outputs
3 - number of setups 1 - for video
3 - for SDI
4 - for remote panel
5 - for RS-422 controller 14
NOTES on the above table:
NOTE 1 - When the master switcher is reset, (e.g. when it is turned on), the reset code is sent to the
PC. If this code is sent to the switchers, it will reset according to the present power-down settings.
NOTE 2 - These are bi-directional definitions. That is, if the switcher receives the code, it will perform
the instruction; and if the instruction is performed (due to a keystroke operation on the front panel),
then these codes are sent. For example, if the HEX code
01
85 88 83
was sent from the PC, then the switcher (machine 3) will switch input 5 to output 8. If the user
switched input 1 to output 7 using the front panel keypad, then the switcher will send HEX codes:
41
81 87 83
to the PC.
When the PC sends one of the commands in this group to the switcher, then, if the instruction is valid,
the switcher replies by sending to the PC the same four bytes that it was sent (except for the first
byte, where the DESTINATION bit is set high).
NOTE 3 - SETUP # 0 is the present setting. SETUP # 1 and higher are the settings saved in the
switcher's memory, (i.e. those used for Store and Recall).
NOTE 4 - The reply to a "REQUEST" instruction is as follows: the same instruction and INPUT codes
as were sent are returned, and the OUTPUT is assigned the value of the requested parameter. The
replies to instructions 10 and 11 are as per the definitions in instructions 7 and 8 respectively. For
example, if the present status of machine number 5 is breakaway setting, then the reply to the HEX
code
0B
80 80 85
would be HEX codes
4B
80 81 85
NOTE 8 - The reply is as in TYPE 3 above, except that here the OUTPUT is assigned with the value
0 if the setup is not defined / no valid input is detected; or 1 if it is defined / valid input is detected.
