Your Audio-Video Matrix Switcher
7
7
Table 2: Front Panel Unit Features
# Feature Function
1 IR Receiver The red LED is illuminated when receiving signals from the Kramer Infra-
red remote control transmitter
2 POWER Switch Illuminated switch supplying power to the unit
3 ALL Button Pressing ALL followed by an INPUT button, connects that input to all outputs
4 OFF Button An OFF-OUT combination disconnects that output from the inputs; an OFF-
ALL combination disconnects all the outputs
5 STO Button Stores the current setting in the non-volatile memory
6 RCL Button Recalls a setup from the non-volatile memory
7 VIDEO Button When pressed 1
8
actions relate to video independently from audio
AUDIO Button When pressed 2
9
actions relate to audio independently from video
AFV Button When pressed actions relate to video and audio channels. Audio channels
follow the video channels, and the AFV button is illuminated
10 LCD MATRIX Display 3 Displays the selected input(s) switched to the output(s) (above or below the
corresponding OUTPUT label) and user interface messages
11 LCD STATUS Display 3 Displays the matrix status (input to output connections)
12 OUT Buttons Select the output to which the input is switched
13 IN Buttons Select the input to switch to the output
14 MENU Button Selects the programming commands to setup the switcher
15 TAKE LED Shows the current TAKE button mode
16 TAKE Button Used to confirm and complete setup and switching
Table 3: Rear Panel Unit Features
# Feature Function
17
SYN
C IN BNC Connector Connect to the external video sync source
18 LOOP BNC Connector Connect to the SYNC IN connector on the next unit
19 TERM Button Press to terminate at 75Ω or release for looping (push in to terminate
the sync line. Push out when the sync line extends to another unit)
20 EXT. (extension) KEYS
Terminal Block Connectors
Connect to an external keyboard (remote unit)
21 RS-485 Detachable
Terminal Block Port
PINS # 1 and # 2 are for vertical sync and Ground connection, and PINS #
3 and # 4 are for RS 485
22 RS-232 IN DB 9F Port Connect to the PC or the Remote Controller 4
23 RS-232 OUT DB 9M Port Connect to the RS-232 IN DB9F port of the next unit in the daisy-chain connection
24 SETUP Dipswitches Dipswitches for setup of the unit
25 OUT Connectors 5 Connect to the audio acceptors 6
26 IN Connectors 5 Connect to the audio sources 6
27 Power Connector with Fuse AC connector enabling power supply to the unit
28 OUT BNC Connectors
Connect to the video acceptors
29 IN BNC Connectors Connect to the video sources
1 The VIDEO button is illuminated when the video breakaway mode is selected
2 The AUDIO button is illuminated when the audio breakaway mode is selected
3 In sections 7.2.5 and 8, the word “Displays” refers to the LCD MATRIX and STATUS Displays
4 If the unit is not the first unit in the line, connects to the RS-232 OUT DB 9F port of the previous unit in the line
5 Terminal blocks on the VS-162AV; RCA connectors on the VS-162AVRCA
6 Balanced on the VS-162AV, unbalanced on the VS-162AVRCA
