K-Router Plus Online User Guide - Defining K-Router Plus 5
3.1 Defining the Menu Bar Items
The following table explains the functions available on the menu bar.
Note: Active functions appear in black. Inactive functions appear in grey.
Menu Item Function
File Connect/Disconnect Connects and disconnects a router
Exit Closes the K-Router Plus application
Device Device Details Displays and allows changing the router
information and communication parameters
Firmware Update Updates the router firmware from a saved file
EDID Manager Allows loading, viewing and saving an EDID
Restart Device Restarts the connected router
Edit Custom Resolutions Allows the choice and specification of non-
standard resolutions
K-Link Data Routes K-Link data connections
Settings System Colors Allows the selection and customization of system
colors
Help About Displays the K-Router Plus software version and
Kramer contact information
For detailed explanations see Section
‎5
.
3.2 Defining the View Mode
The view mode allows you to view the connections as an I/O list, a matrix or a
combined list and matrix view.
To see the dual mode view:

Click the icon. The I/O list and a matrix display all the connections
( Figure 2 ).
