4 K-Router Plus Online User Guide - Defining K-Router Plus
# Feature Function
1 Menu Bar Shows File, Device, Settings and Help submenus (see Section ‎3.1)
2 Tool Button Bar
Connects and disconnects a router
Refreshes all router information to the program
View Mode displays the I/O list and matrix views together
View Mode displays a matrix view only
View Mode displays the I/O list only
Take Sets up the switch, actuates the change, x cancels
the take.
Note: K-Router Plus displays the change on screen but the device does
not switch until the actuate button is pushed
Preset saves the present state to a preset memory location (in
this example 1 –16, the number varies according to the machine)
Preset loads a saved state from a preset memory location
3 I/O Button Bar
Selects all outputs. Together with OFF disconnects all
inputs and outputs
Deselects all outputs
Turns off the selected input
4 OUTPUT
Buttons Select the target output(s) (1 – n)
The number of output buttons match the configuration of your router
5 Output Check
Box Allows choosing multiple outputs
6 Active Status
Indicator On input and output buttons, lights red if inactive, green if active
7 INPUT Buttons Select the target input (1 – n)
The number of input buttons match the configuration of your router
8 MATRIX VIEW Displays all active crosspoint connections; click at an intersection to
make a new connection
9 STATUS Indicates the type of router, its connection method and if the device is
connected or not
