K-Router Plus Online User Guide - Using K-Router Plus
4
Using K-Router Plus
This section explains how to operate the main functions of K-Router Plus.
4.1
Connecting a Router
To connect a router:
1. Physically connect a router via RS-232, USB or a network to a PC running
K-Router Plus.
2. Click the menu item File > Connect or click the Connect button.
The Connection Method screen opens:
Figure 5: Connection Method Window
3. Choose the appropriate connection method, set the parameters as required
and click Connect.
4.2
Switching Inputs to Outputs
To switch inputs to outputs:
In the list view, click the desired output button then the desired input button
In the matrix view, click the intersection of the desired input and output
