VS-41AV, VS101AV, VS-4X - Technical Specifications
11
5
Technical Specifications
VS-41AV
VS-101AV
VS-4X
INPUTS:
4 video, 1Vpp/75
Ω on
BNC connectors,
4 stereo audio, +4dBu
typical, on RCA
connectors
10 video, 1Vpp/75
Ω on
BNC connectors,
10 unbalanced stereo
audio, +4dBu typical, on
RCA connectors
4 balanced stereo
audio, +4dBu typical, on
XLR connectors
OUTPUTS:
1 video, 1Vpp/75
Ω on a
BNC connector,
1 stereo audio, +4dBu
typical, on an RCA
connector
1 video, 1Vpp/75
Ω on a
BNC connector,
1 unbalanced stereo
audio, +4dBu typical, on
an RCA connector
1 balanced stereo
audio, +4dBu typical, on
an XLR connector
SWITCHING
SYSTEM:
Mechanical, "Break-
before-make",
Audio- Follow-Video
mode
Mechanical, "Break-
before-make",
Audio- Follow-Video
mode
Mechanical, "Break-
before-make"
BANDWIDTH:
Video: 520MHz (–3dB)
Audio: 100kHz (–3dB)
Video: 500MHz (–3dB)
Audio: 100kHz (–3dB)
Audio: 100kHz (–3dB)
CROSSPOINTS:
4 for video, 4x2 for
audio, 1 set active at
any given time
10 for video, 10x2 for
audio, 1 set active at any
given time
4x2 for stereo audio
SIGNAL LEVELS:
Video: Up to 3Vpp
Audio: +30dBu
Video: Up to 3Vpp
Audio: +30dBu
Up to +30dBu
DIMENSIONS
(W, D, H):
18.8cmx10.2cmx4.4cm
(7.4" x 4" x 1.7")
48.3cmx10.2cmx4.4cm
(19" x 4" x 1U)
15.3cmx6.6cmx7.6cm
(6” x 2.6” x 3”)
WEIGHT:
0.65kg(1.44lbs) approx
1.5kg (3.3lbs) approx
0.57kg (1.27lbs) approx
OPTIONS:
RK
−81 19” rack adapter
RK
−4X 19" rack adapter
Specifications are subject to change without notice a
