background image

Connecting the VM-24HDCP

11

11

To cycle between the different modes (One Output, Default and Auto-mix),
as defined in

Table 2

, press the EDID SELECT button

Table 2: The EDID Modes

Current

EDID Mode

Appearance

To cycle to the

Default EDID

To cycle to the
Auto-mix EDID

To cycle to the

One output EDID

One Output

The selected output

LED flashes

Press the EDID

SELECT button
once again after
selecting output 4.
The output LEDS
flash

Default

The output LEDs

flash simultaneously

Press the EDID

SELECT button
once

Auto-mix

The output LEDs

flash in sequence

Press the EDID

SELECT button to
select the required
output the selected
output flashes

To acquire or change the EDID of a new output display from:
• One output, see

Section 6.3.1

• The default EDID, see

Section 6.3.2

• Several connected outputs, see

Section 6.3.3

6.3.1 Acquiring / Changing the EDID from One Output

To acquire or change the EDID of a new output display:

1. Connect the power supply.

2. Connect the new output display device.

3. Press the EDID SELECT button, enter the One output mode as defined in

Table 2

, and set to the connected output.

The appropriate OUTPUT STATUS LED flashes, indicating that that
output channel is selected.

4. Press the EDID READ button to copy the EDID of the selected OUTPUT

to the inputs

1

.

While the EDID is being copied, the EDID SELECT and READ buttons
illuminate.
The new EDID is copied when both buttons no longer illuminate.



1 If you want to cancel the EDID modification, wait for a few seconds without touching any button
