DGO−...−A−B
Festo DGO−...−A−B 0410b English
30
13 Technical specifications
DGO−... 12 16 20 25 32 40
Medium Filtered compressed air, lubricated or non−lubricated; other media on
demand
Design Double−acting, with magnet coupling, without piston rod
Pressure range [bar] 2Ă...Ă7 1.7Ă...Ă7 1.6Ă...Ă7 1.5Ă...Ă7 1.4Ă...Ă7 1.3Ă...Ă7
Temperature range − 20 ... + 60 °C
Connections
Fastening for the
cylinder barrel M
16 x 1.5 M
16 x 1.5 M
22 x 1.5 M
22 x 1.5 M
30 x 1.5 M
38ĂxĂ1.5
Compressed air port M 5 M 5 G 1/8 G 1/8 G 1/8 G 1/4
Fastening the load M 5 M 6 M 8
Lubricating nipple DIN 3405 AM 6
Magnetic pull−off
strength 100 N 160 N 270 N 400 N 680 N 1050 N
Theor. force at 6 bar 68 N 121 N 188 N 295 N 483 N 754 N
Mounting position As desired
End position
cushioning Pneumatic, adjustable (not with DGO−12−...−P−A−B)
Cushioning length ć 14 mm 17 mm 19 mm 20 mm 23 mm
Axial torsional
strength of the
external slide 360°
Materials Slide and end cover: Al (anodized):
Cylinder barrel: Steel, stainless
Seals: Buna N; polyurethane
