DG..−...−GA, FDG−...−GA, DMES−...−GA
Festo DG..−...−GA, FDG−...−GA, DMES−...−GA 0503a English
9
Protected guide for linear axis
type DG..−...KF−GA / FDG−...−GA / DMES−...−GA
English
1
Operating parts and connections
1
2
3
4
5
6
7
8
1
Cover profile
2
Brush wiper
3
Support screws
4
Slide
5
Guide rail (not visible)
6
Profile support
7
Through hole for shock absorber
8
Threaded hole for stop bolt
Fig. 1
