DG..−...−GA, FDG−...−GA, DMES−...−GA
Festo DG..−...−GA, FDG−...−GA, DMES−...−GA 0503a English
14
9
Accessories
Title
Type
Cover for the fastening groove
ABP−5−...
Sliding block for fastening the work load
NSTL−...
Centring pin (8 ... 18)
ZBS−5
Centring sleeve (25 ... 80)
ZBH−9
Centring disc
SLZZ−...
Shock absorber support
KYP−...
Shock absorber
YSR−...
Shock absorber with assembly kit for profile support
DG−GA−...−YSR
Fig. 11
10
Technical specifications
Type
...−GA
Variant element for
DGE−...−ZR, DGE−...−SP, DGPL−..., DGPIL−..., FDG−...,
DMES−... (not permitted for DGE−...−RF)
Mounting position
Horizontal (max. deviation ± 15°)
Guide rail must always face upwards
Area of application
Only with dirt particles falling down
Not with dirt particles whirled up
Permitted temperature range
− 10 ... + 60 °C
Materials
Cover rail:
Al
Brush wiper:
ABS, steel, horsehair
Caps:
PE, PAC
Fig. 12
