Specifications

Environment

CCTV HD-SDI

Device Targeted

HD-SDI (up to 1080i) CCTV equipment that need to bring power
and control using a single UTP cable.

Compatible RX Unit

M500720, M500720-CL, M500721

Compatible mounting
hardware

M500902, M500900, M500910, M500915

Signal Transmission

Signal: SDI (no analog),
Power: 12VDC or 24VAC 2A max,
Control signal: any signal using a balanced pair, 1A max.

Cabling Requirement

Any 4-pair straight cable Cat5e or 6, 24 AWG or lower.

Connectors

One 75 ohm BNC connector, female.
One 4 pin terminal block for power and signal.

RJ45 Pin Configuration

Pin 7-8 for SDI signal
Pin 1+3, 2+6 for power (1&3 in parallel, 2&6 in parallel)
Pin 4-5 for control

Maximum distance

Combine with M500721:
SD: more than 120m (400ft) for CAT 5E UTP,
More than 150m (500ft) for CAT 6 UTP.
HD: Up to 30m (100ft) using Cat 5E UTP,
up to 45m (150ft) for CAT 6 UTP.

Combine with another M500720 or -CL:
SD: Up to 120m (400ft) for CAT 5E UTP,
up to 150m (500ft) for CAT 6 UTP.
HD: Up to 30m (100ft) using Cat 5E UTP,
up to 35m (120ft) for CAT 6 UTP.

Note: Maximum distance is function of the receiving equipment
and cable. Dedicated Cat5E/6 cables are recommended with no
patch panels.
This balun will not work in 3G (1080p).

Temperature

Operating: -40° to 60°C (-40° to 140°F)
Storage: -40° to 85°C (-40° to 185°F)

Humidity

Maximum 95% (non-condensing)

Enclosure

ABS UL94HB fire retardant plastic

Dimensions

6 x 5.5 x 2.5 cm (2.4” x 2.25” x 1.0”)

Weight

60g (2 oz.)

Warranty

Lifetime

Order Information

M500720 HD CCTV Pass-Thru Balun



HD CCTV Pass-Thru Balun

500720

Quick Installation Guide

Overview
The Balun (M500720) allows one HD-SDI signal with power and control lines to be
transmitted up to 150 ft. (45m) via a Cat5E or Cat6 cable at HD resolution (720p, 1080i)
in a point-to-point configuration. The balun supports transmission of SDI digital video
(including embedded Audio and/or Time Code) within facilities and between video
equipment. This balun can be combined with another M500720 or M500720-CL. For
the maximum distance use the M500721.

Applications
HD-CCTV surveillance system
