RMS Technologies Page 25 Version 1.20
R325IE Single Axis Controller/Driver Manual 02/13/2006
12. Troubleshooting
R325IE is not functioning correctly
Try putting the R325 into TEST mode by placing a jumper on Pins 9 & 10 of JP2. The
motor should twitch back and forth slightly if the R325IE is functioning properly.
R325IE not moving the motor (Step/Dir)
Verify that the 5V is being supplied to Pin 1.
The R325IE is causing the motor to vibrate and jitter back and forth
Are the Motor phases switched? Be sure to check that motor wires are connected to
Pins 6 through 9 of P1, in the order of A, A Bar, B, B Bar. To check which wires
belong to one phase, take a Meter to measure resistance between any two wires. If
there is a finite value between two of them, insert the wires into pins 6 and 7, OR
pins 8 and 9. Insert the remaining two wires accordingly.
