R325IE Single Axis Controller/Driver Manual 02/13/2006
Setting the Current
There are two current settings on the R325IE.
1. Run Current (RI) – The peak current that the motor will be run at while in
motion.
NOTE: Current of 2.7 Amp and above REQUIRES an additional heatsink, make sure the
temperature of the bracket does not exceed 45° C.
2. Hold Current (HI) – The current that the motor will receive when idle.
*The default board address of ‘A’ is used in all examples, please see “MA” command for more
detail on addresses.
Examples:
To set Run Current to 2000mA (2.0A):
#ARI2000
To set Hold Current to 300mA (0.3A):
#AHI300
Setting Step Resolution
The R325IE is capable of full stepping or 2, 4, 8, 16, 32, 64, 128, and 256
microstepping.
Example:
To set Step Resolution to 4x microstepping:
#ASR4
Saving the Configuration
In order to have these settings retained upon a power cycle, the data must be saved.
The command to store these settings is “SD” (Save Data).
Example:
To save settings:
#ASD
Connecting the Motor
WARNING! Make sure the power is OFF when connecting or
disconnecting motors from the R325IE. Damage will occur if the
power is being supplied.
Please refer to your motor documentation for wiring color code.
Connect the corresponding Phase from the motor to the proper pin on the R325.
Motor Phase
P1 Connector
Phase A Pin 6
Phase A- Pin 7
Phase B Pin 8
Phase B- Pin 9
Using the R325IE
If using the R325IE in Step/Direction mode, remove the jumper from Pins 7 & 8 on
JP1, and proceed to Section 8 – Basic Step and Direction Operation.
If using the R325IE as a simple controller, please insure that there is a jumper on
Pins 7 & 8 on JP1, and refer to the Command Tables in Section 9 and more detailed
descriptions of the Commands in Section 10.
