RMS Technologies R325 DRIVER W/PDT - Manual (Page 21)

RMS Technologies Page 21 Version 1.20
R325IE Single Axis Controller/Driver Manual 02/13/2006
Command
(Case Sensitive)
Operand Example Description
MISC
PF 0, 1, 2, 3 #ACD1
Sets Mixed
Mode damping
to 15% Percent Fast Decay - Command or Query
Default = 2
- Allows the Damping Mode of the driver IC to be set.
0 = Fast Decay
1 = Mixed Mode 15%
2 = Mixed Mode 48%
3 = 100%
The optimum setting will vary with motor inductance and step
rate; however the default ‘Mixed Mode’ setting will work well with
almost all motors.
MICROSTEPPING
SR 1, 2, 4, 8, 16,
32, 64, 128,
256
#ASR4
Sets the step
resolution to 4x Step Resolution - Command or Query
Default = 16
- Reads or sets the current step resolution
Allowed values are:
256 for 256x
128 for 128x
64 for 64x
32 for 32x
16 for 16x
8 for 8x
4 for 4x
2 for 2x
1 for 1x
QUERY COMMANDS
FR - #AFR Firmware Revision - Query Only
- Returns 3 digit part code followed by 3 digit firmware revision
value.
Reply
*AFR325100 //R325 firmware revision 1.00
MA 65 - 90 #AMA88
Sets the unit
address to 88
(‘X’) My Address - Command or Query
Default = 65
- Reads or sets the unit address. The value read or entered is the
decimal value of the ASCII character designated as the unit
address. (65 = ‘A’ and 90 = ‘Z’)
The change to a new address is immediate, in that the command
response will use the new address
RS - #ARS
Reads the
switch inputs Read Switches - Query Only
- Reads the TRUE (1) or FALSE (0) state of the three optically
coupled inputs, combined into a single three-bit value. This
command is used to check the correct operation of this interface.
- The value order of the inputs is ‘Direction’, ‘Disable’, and ‘Step’;
in descending order.
‘Direction’ has the value 4 (100)
‘Disable’ has the value 2 (010)
‘Step’ has the value 1 (001)
TI - #ATI
Reads the
switch inputs Test Inputs - Query Only
Step, Direction, and Disable all return a value in decimal form.
The value order of the inputs is:
‘Direction’, ‘Disable’, and ‘Step’; in descending order.
‘Direction’ has the value 4 (100)
‘Disable’ has the value 2 (010)
‘Step’ has the value 1 (001)
Reply
*ATI3 // 3 = ‘011’
