Rugged Ridge 6-Piece Body Armor Kit, 97-06 Jeep Wrangler (TJ) User Manual
Page 3
Step 4: Position Hood Armor close to the hood and attach from the center of
hood outward to the edges. Make sure that it is evenly spaced before applying
any pressure to armor. When satisfied with placement apply pressure to all areas
to properly secure armor to vehicle.
Step 5: After installation, inspect to make sure all tape areas are adhered
securely to the vehicle before driving.
NOTE: it is important that the Hood Armor be positioned as far back onto
the hood as possible. There should be NO GAP between the front of the
hood and the inside of the Hood Armor
Step 6: With Hood Armor in the correct position and firmly attached to the vehicle
mark or scribe two hole locations on each side of the inner hood. These marks
are to be drilled using a 7/64” drill bit. Make sure mark locations are positioned as
far inward as possible. This will allow the screws to be located flush with the
hood and grille line when lowered. With marks in place carefully drill the two
7/64” holes.
TAKE CARE NOT TO DRILL TO FAR PAST THE INNER LIP OR
DAMAGE TO OUTER HOOD SURFACE MAY RESULT.
