Team Associated RC10B5 User Manual
Page 6
6
:: Shock Towers and Rear Chassis Brace Build - Bag C - Step 3
91412
Rear
Arms
31521
M2.5 x 8mm
BHCS
25187
M3 x 14mm
BHCS
91379
Chassis
Plate
91382
Arm Mount,
C (3+2)
91382
Arm Mount,
D
x2
x2
91394
Hinge Pin
(rear, Inner)
:: Shock Towers and Rear Chassis Brace Build - Bag C - Step 2
89204
M3 x 24mm
BHCS
89202
M3 x 12mm
BHCS
91477
M3 Nut
(black)
91373
Front Shock
Tower
91049
Heavy-duty
Ballstud, 10mm
x2
x4
x2
x2
31286
FT Ballstud
Washer,
aluminum
(2mm, blue)
:: Shock Towers and Rear Chassis Brace Build - Bag C - Step 1
25204
M3 x 16mm
FHCS
91410
Front
Bumper
91394
Hinge Pin
(front, Inner)
91371
Front Hinge
Pin Brace
31521
M2.5 x 8mm
BHCS
x2
x2
