Team Associated RC12R5.2 - Manual (Page 8)

8
897
3/8 x 1/4
flanged
bearing
:: Rear Axle Build - Bag D-DD - Step 2
:: Servo / Top Plate Build - Bag E-EE - Step 1
:: Servo / Top Plate Build - Bag E-EE - Step 2
4630
Servo
mount
4624
Servo mount
spacer
4349
Ride height
adjuster #4
31532
M3x8mm
bhcs
7337
M3x0.5mm
washer
4554
Rear axle
shims, .005”
4567
Left
wheel
hub
4568
2-56x5/16
shcs
x2
x4
x4
x4
Note:
this end onto
rear axle first
Servo not
included
Ackerman
Adjustment
Spacers
Note:
use spacers to adjust
ackerman settings
x2
31280
Ballstud
short, 5mm
31540
M3x5mm
fhcs
31550
M3x0.5mm
locking nut
x2
x2
x2
Screw not
included
3760
Servo saver
(airtronics)
