Team Associated RC12R5.2 - Manual (Page 7)

7
:: Front Bulkhead Build - Bag C-CC - Step 4
:: Front Bulkhead Build - Bag C-CC - Step 5
:: Rear Axle Build - Bag D-DD - Step 1
Caster Adjustments
1.80°
6.15°
3.25°
standard
Caster Spacers
0.8mm 1.2mm
Bellville Washers
) ( (
25201
M3x8mm
fhcs
6619
.125 carbide
diff balls
8504
Diff
d-ring
4698
LiPo hinge
pin brace
4617
Front
bulkhead
shim
(1mm)
4624
Caster
spacers
4459
Bellville
washer
4608
Right
wheel
hub
4565
Rear
axle
4185
Plastic
nut
4615
Spur gear
96T
4623
Upper
hinge pin
31510
M2x4mm
bhcs
x4
x12
x2
x3
x4
x4
x3
x2
x2
4609
Diff thrust
cone
897
3/8 x 1/4
flanged
bearing
#6636
S. diff grease
Bulkhead Shims
0.5mm 1mm 2mm
