Team Associated RC12R5.2 - Manual (Page 3)

3
:: Shock Build - Bag A-AA - Step 1
:: Shock Build - Bag A-AA - Step 2
:: Turnbuckles / Side Dampers Build - Bag A-AA - Step - 3
4661
Threaded
shock
collar
4664
Thru
shaft
4660
Shock
body
4662
Shock
bottom
nut
4637
Pivot
ball
4662
Shock
o-ring
bearing
4663
Micro VCS
o-ring
4662
Shock
thru cap
4665
Shock
rod end
7230
Ball cup,
large
4671
M3x10mm
set screw
4709
Damper
tube shaft
4708
Damper
tube
31500
M3x0.5x2.5
set screw
4661
Spring
cup
8452
Micro VCS
shock spring
(blue, 10lb)
4663
Micro VCS
o-ring
4662
Shock
o-ring
bearing
Shock oil
#5422
(30wt)
Shock oil
#5422
(30wt)
Shock oil
#5422
(30wt)
Build two
turnbuckles
Build two
dampers
!
!
Steering Turnbuckle
1403
FT blue Ti
turnbuckle
(1.65”)
31305
Turnbuckle
eyelet
8828
Anti roll
bar cup
set
56.40mm
x2
x2
#6636
S. diff grease
