Team Associated RC12R5.2 - Manual (Page 4)

4
:: Pivot Brace Build - Bag B-BB - Step 1
:: Pivot Brace Build - Bag B-BB - Step 2
:: Rear Bulkhead Build - Bag B-BB - Step 3
4637
Pivot ball
4672
M2x6mm
bhcs
4673
M2.5x4mm
bhcs
25202
M3x10mm
fhcs
31540
M3x5mm
fhcs
31530
M3x5mm
bhcs
31550
M3x0.5mm
locknut
(blue)
4635
Pivot
brace cap
4700
Motor
mount
4702
Motor
mount
brace
4637
Pivot ball
31540
M3x5mm
fhcs
4635
Rear
pod link
4635
Pivot
brace
4701
Left rear
bulkhead
31540
M3x5mm
fhcs
4691
Chassis
4692
Lower
pod plate
x4
x4
x2
x2
x4 x4
x2
x4
x2
Note:
Use screws to
adjust for
free pivot ball
movement
Note:
Use screws to adjust for
free pivot ball movement
Note:
Shoulder on
pivot ball
should pont
downward
Note:
Shoulder on pivot ball
should pont downward
Note:
Leave the locknuts
loose, rock the
chassis and the
lower rear pod
plate side to side.
Slowly tighten
each side so the
plates rotate
freely.
!
!
!
!
!
