25 FPM-8192V/8232V User Manual
Chapter 3
O
perating
the
LCD
Display
Press “ ” and “ ” to select the PIP Display main source, including VGA, DVI,
Composite, and S-Video mode.
Press “ ” to choose “Select”.
3.7.6 Audio Item Menu (Optional)
Figure 3.14 Audio Item Menu
Audio Item Menu
Menu
Input Source Description and Usage
Volume VGA
DVI
Composite S-
Video
To adjust the volume, use “ ” / “ ” to change the value of
the slider bar to increase or decrease the volume.
Balance
To configure the audio balance, either left or right, use “ ” /
“ ” to change the value of the slider bar to change the value.
Treble
Increase or decrease the audio treble by using “ ” / “ ” to
change the value.
Bass
To configure the bass, use “ ” / “ ” to change the bass
value.
Mute To turn mute off/on, select either On/Off for Mute. By default,
mute is set to No, or turned off.
