EasyUSB AudioBRIDGE
Easy USB AudioBRIDGE - Document Number 342-0769 Rev B Page 13 of 16
Technical Specifications
EasyUSB AudioBRIDGE
Part Numbers EasyUSB AudioBRIDGE 999-8536-000 (North America)
EasyUSB AudioBRIDGE 999-8536-001 (International)
Audio Specifications Frequency Response: 20 HZ to 20 kHz
Dynamic Range: >90dB
THD + Noise: <.02%
Unbalanced Analog
Line Input Connector: RCA
Impedance: 10K ohm
Nominal Level: -10dBV
Balanced Analog Line
Input Connector: 3-Pin Euro Terminal Block
Impedance: 10K ohm
Nominal Level: +4dBu
Unbalanced Analog
Line Output Connector: RCA
Impedance: 10K ohm
Nominal Level: -10dBV
Balanced Analog Line
Output Connector: 3-Pin Euro Terminal Block
Impedance: 50 ohm
Nominal Level: +4dBu
USB Audio Interface Connector: Type-B Female
Type: USB 2.0 Compliant
PC Audio Controls: Mute & Volume
PC HID Controls: On/Off Hook (application dependent)
Dip Switch Settings 8-Position Dip Switch, Operational Settings
User Indicators Power Status (blue LED on front panel)
Power Supply 18 VDC, 1.0 Amp, Switching Power Supply
5.5mm OD x 2.5mm ID Coaxial Connector with Positive Center
Serial Control
Protocol RS-232 (external control), 38.4K baud
General Information
Operating
Temperature 32° to 104° F (0° to 40° C), 20% to 80% Relative Humidity
Power Consumption <18 watts
Dimensions
(H x W x D) 1.72” (43.7mm) H x 8.375” (212.73mm) W x 6.0” (152.4mm) D
Weight Approximately 1.4015643 lbs. (0.63573887 kg)
Country of Origin Designed and Manufactured in the USA (Vaddio HQ in Minnetonka, Minnesota)
