Operating Instructions Alarm/Light Module XWA11V
01/14 Rev F. 142498 Page
7
13. PARAMETER MAP
LABEL DESCRIPTION VALUE LEVEL RANGE
ot Thermostat probe calibration 0 Pr2 [-21°F - 21°F]
CF Temperature measurement unit F Pr2 °C - °F
rES Resolution (only for °C) in Pr2 dE - in
UT Display update 60 Pr2 0 - 255 (sec.)
OnF Off function enabling y Pr2 n - Y
ALU High temperature alarm setting (med temp / low temp) 50 / 30 Pr1 ALL-302° F
ALL Low temperature alarm setting (med temp / low temp) 30 / -20 Pr1 °-58 - ALU
AFH Temperature alarm differential 2 Pr2 1°F - 45°F
ALd Temperature alarm delay 30 Pr1 0 - 255 (min.)
dAo Delay of temperature alarm at start-up 1.3 Pr2 0.0 - 24.0 Hrs.
EdA Alarm delay at the end of defrost 30 Pr2 0 - 255 (min.)
dot Delay of temperature alarm after closing the door 15 Pr2 0 - 255 (min.)
LHt Light timer 15 Pr1 0 - 255 (min.)
FLH Light Flashing Timer (time before light goes out that it will flash) (for incandescent & LED lights only) 2 Pr1 0 - 5 (Min)
doA Open door alarm delay 15 Pr1 0 - 255 (min.)
oA1 First relay configuration ALr Pr2 ALr - LHt - OnF
oA2 Second relay configuration LHt Pr2 ALr - LHt - OnF
AOP Alarm relay polarity oP Pr2 OP - CL
i1P Digital input 1 polarity CLoP Pr2 OP - CL
i1L Door switch to turn light ON y Pr2 n - Y
i1F Digital input 1 operating mode dor Pr2 EAL - dor - dEr - LHt
i2P Digital input 2 polarity cL Pr2 OP - CL
i2F Digital input 2 operating mode PAn Pr2 EAL - Pan - dFr - LHt
did Time interval/delay for digital input alarm 0 Pr2 0 - 255 (min.)
tbA Alarm relay disabling n Pr2 n - Y
PbC Kind of probe ntc Pr2 PtC - ntC
dP1 Real temperature Probe 1 Pr2 (probe value)
rEL FW release Pr2 read only
Ptb Parameter map Pr2 read only
