Operating Instructions Alarm/Light Module XWA11V
01/14 Rev F. 142498
Page
17
Installation:
1. Mount the remote buzzer box in the location desired.
2. Drill the appropriate size hole for the conduit fitting into the Wall Mount Box P/N 142456.
3. Conduit, conduit fittings, and wire are by others.
Installation must be by a qualified electrician per the applicable national and local codes.
4. Connect a black wire to terminal #4 and a white wire to terminal #13 of the Phone Relay in the Wall
5. Mount Box.
