E2 SERVICE MANUAL REV D 09/12
47
Error
Code
Oven
Error/Event
Condition
Description Trigger
Error
Level
System
Response
E094 E3, E4, E5
Recommission fail -
Filter in
The oven does
not sense that the
filter is installed The SRB does not
see the magnetic
switch input from
the air filter while
the “INSTALL AIR
FILTER” message
N/A
"E094
RECOMMISSIO
N FAIL FILTER
INSTALL"
message is
written to the
E095 E3, E4, E5
Recommission fail -
Filter out
The oven does
not sense that the
filter has been
removed The SRB does not
see the magnetic
switch input from
the air filter while
the “REMOVE AIR
FILTER” message
N/A
"E095
RECOMMISSIO
N FAIL FILTER
REMOVAL"
message is
written to the
E096 All
Recommission fail -
Door close
The oven door
switch has failed
the door close
test The SRB does not
see the switch
input from the door
while the “CLOSE
OVEN DOOR”
message is
N/A
"E096
RECOMMISSIO
N FAIL DOOR
CLOSE"
message is
written to the
E097 All
Recommission fail -
Door open
The oven door
switch has failed
the door open test The SRB does not
see the magnetic
switch input from
the air filter while
the “OPEN OVEN
DOOR” message
N/A
"E097
RECOMMISSIO
N FAIL DOOR
OPEN"
message is
written to the
E098 All Incomplete Cleaning
The QTS has
determined that
the cleaning
process was
started but not
completed Only tested for
when oven turns
on. The QTS has
found that during
the previous oven
on period, a
Warning
"E098
INCOMPLETE
CLEANING"
message is
displayed in the
error log.
E099 E3, E4, E5 Filter Override
User has removed
the filter and
elected to
continue cooking User removes the
air filter. On the
screen where the
message “AIR
FILTER
REMOVED” and
Warning
"E099 FILTER
OVERRIDE"
message is
displayed in the
error log.
E100 All Main power ON
The AC power to
the oven is
energized The SRB is reset
after 25V AC
power is applied
from the
transformer
N/A
"E100 MAIN
POWER ON"
message is
written to the
ovens error log
E101 All Magnetron failed
Magnetron failed
to turn On when
requested The current
measured by the
SRB was outside
of the tolerance
range
Critical
"E101
MAGNETRON
FAILED"
message is
written to the
error log.
