PR Parts List
Part
No.
Description
Sizes 8 - 30 Sizes 36 - 48
1 Topcap Topcap
2 Post (4) Post (8)
3 Base Base
4 Inlet Inlet
Not Shown Birdscreen (optional)
Corporate Offices: 2015 E. Dale Street Springfield, MO 65803 417.869.6474
www.lorencook.com
Limited Warranty
Loren Cook Company warrants that your Loren Cook fan was manufactured free of defects in materials and workmanship, to the extent stated herein. For a period of five (5)
years after date of shipment, we will replace any parts found to be defective without charge, except for shipping costs which will be paid by you. This warranty is granted only
to the original purchaser placing the fan in service. This warranty is void if the fan or any part thereof has been altered or modified from its original design or has been abused,
misused, damaged or is in worn condition or if the fan has been used other than for the uses described in the company manual. This warranty does not cover defects resulting
from normal wear and tear. To make a warranty claim, notify Loren Cook Company, General Offices, 2015 East Dale Street, Springfield, Missouri 65803-4637, explaining in
writing, in detail, your complaint and referring to the specific model and serial numbers of your fan. Upon receipt by Loren Cook Company of your written complaint, you will be
notified, within thirty (30) days of our receipt of your complaint, in writing, as to the manner in which your claim will be handled. If you are entitled to warranty relief, a warranty
adjustment will be completed within sixty (60) business days of the receipt of your written complaint by Loren Cook Company. This warranty gives only the original purchaser
placing the fan in service specifically the right. You may have other legal rights which vary from state to state.
PR / TR / LSUG IOM - Feb 2013
Part
No.
Description
Sizes 8-30 Sizes 36 - 48
1 Topcap Topcap
2 Open Tiered Topcap Open Tiered Topcap
3 Post (8) Post (16)
4 Base Base
5 Inlet Inlet
Not Shown Birdscreen (optional)
TR Parts List
Part
No.
Description
Size 20-36 Size 42-60
1
Damper Stop Brackets /
Lifting Lugs (2)
Damper Stop Brackets /
Lifting Lugs (2)
2 Damper Stop Channel Damper Stop Channel
3 Damper Bumpers (2) Damper Bumpers (2)
4 Windband Windband
5 Base Weldment Base Weldment
6 Rain Gutter Rain Gutter
7 Damper Door (2) Damper Doors (2)
8 Damper HInges (4) Damper HInges (8)
9 Damper Pivot Rod Damper Pivot Rod
10
Damper Pivot
Brackets (2)
Damper Pivot
Brackets (2)
LSUG Parts List
