Curb with wood nailer, Curb without wood nailer, Hinge side view – COOK Hinged Base User Manual
Page 2
2
1/8" Pop Rivet
Head on Inside
of Base
1/4" Kwik Drill
Sheetmetal Screw (3)
1/4" Kwik Drill
Sheetmetal Screw (2)
1-1/2" Wood Screw
Hinge Plate
Hinge Side
View
Hinged Base Supplemental Installation Instructions (continued)
Corporate Offices:
2015 E. Dale Street
Springfield, MO 65803 417.869.6474
www.lorencook.com
September 2001
Installation on Vented Extension or Curb without Wood Nailer
A
5/16 x 1-1/2 Bolt
Center Punch
Template
T.Sq.
Base Latch Plate
Cable Clamp
Aircraft Cable
Cable Clamp
Curb Latch Plate
Latch Side
View
Wood Screws
Installation on Curb with Wood Nailer
(Figure 1)
(Figure 2)
