e-Train Data™ 13
Viewing a selected interval
Let’s select the interval you want to see, by using [Analysis] button.
1. Click [Analysis] button.
2. Move the pointer on the graph and it becomes + pointer.
Choose the start of the interval and click the point.
A vertical line appears on the start point and its time appears at the top of the line.
3. Choose the end of the interval and click the point.
A vertical line appears and its time appears on the top of the line.
At the same time, in the right columns of the table, maximum, minimum and average data of
the selected interval are shown.
Maximum, minimum & average data of
the entire graph
Maximum, minimum & average data
of the selected interval
Selected interval
↑
End point
↑
Start point
Time of start point
Time of end point
