Operation
35 802031 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Step 7: Select Prewash if Desired
Figure 40
Step 8: Press Start
After vend price has been satisfied, push the START
keypad. DOOR MUST BE CLOSED TO START
WASHER.
Figure 41
Indicator Lights
In Use
Figure 42
IN USE is lit at the beginning of a wash cycle and will
remain lit until the wash cycle is complete.
Rinse
Figure 43
RINSE is lit at the beginning of all rinse cycles and
will remain lit until the rinse cycle is complete.
Spin
Figure 44
SPIN is lit for all spin cycles.
Door Locked
Figure 45
DOOR LOCKED is lit whenever the door is locked.
The door cannot be opened when this light is on.
IMPORTANT: If washer fails to operate properly
after installation, make sure electrical service and
water supply faucets are turned on. Are all the
controls properly set? Have a qualified service
person refer to the wiring diagram (located inside
of washer control hood) and check for broken,
loose or incorrect wiring.
NOTE: Once a cycle has started, the door can only
be opened by first unplugging the power cord and
waiting one minute.
FLW1951N
FLW1952N
CPW70
90 40
60 60
30
90 40
60 60
30
IN USE LIGHT
TLW1934N
CPW65
FLW1956N
TLW1934N RINSE LIGHT
SPIN LIGHT
FLW1956N DOOR LOCKED LIGHT
To reduce the risk of bodily injury, do not
remove laundry from washer until all
lights are out, and all moving parts have
stopped.
W092
WARNING
