Installation
802031 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Before You Start
Tools
For most installations, the basic tools you will need
are:
Figure 1
Water
Washer needs two standard 19.1 mm (3/4 inch) water
supply faucets with a pressure between 138 and
827 kPa (20 to 120 pounds per square inch). For more
detailed information, refer to section on Water Supply
Requirements.
Location
Place the unit on a solid floor with an adequate air
supply. For more detailed information, refer to section
on Location Requirements.
Exhaust
Use rigid metal duct and exhaust the dryer to the
outside by the shortest route possible.
NOTE: For more detailed information, refer to
section on Dryer Exhaust Requirements.
Figure 2
Electrical
● WASHER
Refer to serial plate for specific electrical
requirements. For more detailed information,
refer to section on Washer Electrical
Requirements.
● DRYER
Refer to serial plate for specific electrical
requirements.
Dryer needs a 2 wire plus earthing, 230 Volt,
60 Hertz, 30 Amp, single-phase electrical supply.
For more detailed information, refer to section on
Dryer Electrical Requirements.
D814I
1 Wrench
2 Screwdrivers
3 Pliers
4 Socket Wrench
5 Teflon Tape
6 Level
7 Duct Tape
1 2 3
4
5
6
7
H311I
