Installation
Dimensions and Specifications
NOTE: Side and rear exhaust openings are 102 mm
(4 inch) ducting. IMPORTANT: The dryer should have sufficient
clearance around it for needed ventilation and for
the ease of installation and servicing. For maximum
drying performance, we recommend that more
clearance be allowed around the dryer than the
clearances that are listed throughout this manual.
SWD562N
*With leveling legs turned into base.
SWD562N
597 mm
(23.5 in.)
51 mm
(2.0 in.)
178 mm
(7.0 in.)
448 mm
(17.5 in.)
*363 mm
(14.3 in.)
711 mm
(28 in.)
*7
51 mm
(29
.6 in.)
*79
0
m
m
(
31.
1 i
n
.)
*1
943
mm
(7
6.5
in.)
*1
16
3 m
m
(
45.
8 i
n
.)
391 mm
(15.4 in.)
683 mm
(26.9 in.)
51 mm
(2.0 in.)
203 mm
(8.0 in.)
UNITS WITH OLD STYLE DOOR
SWD729N
*With leveling legs turned into base.
SWD729N
597 mm
(23.5 in.)
51 mm
(2.0 in.)
178 mm
(7.0 in.)
475 mm
(18.7 in.)
*363 mm
(14.3 in.)
711 mm
(28 in.)
*751
mm
(2
9.6
in.)
*79
0
mm
(
3
1.
1 in.
)
*1
94
6 m
m
(7
6.
6
i
n
.)
*1
16
3 m
m
(4
5.
8 i
n
.)
391 mm
(15.4 in.)
683 mm
(26.9 in.) 51 mm
(2.0 in.)
203 mm
(8.0 in.)
UNITS WITH NEW STYLE DOOR
