Basic Installation/Operation
Specifications and Dimensions
† For Models with A or M in the 8 th position in the model number (e.g. *X18PVXA6)
†† For Models with U in the 8
th
position in the model number (e.g *X18PVXU6)
(continued)
General Specifications
Model 18 25 33 35 40
Overall Dimensions
Overall width 660 mm
(26 in.)
660 mm
(26 in.)
780 mm
(30.71 in.)
783 mm
(30.8 in.)
780 mm
(30.71 in.)
Overall height 1031 mm
(40.6 in.)
1031 mm
(40.6 in.)
1376 mm
(54.15 in.)
1194 mm
(47 in.)
1376 mm
(54.15 in.)
Overall depth 780 mm
(30.7 in.)
870 mm
(34.3 in.)
840 mm
(33.07 in.)
960 mm
(37.8 in.)
940 mm
(37.01 in.)
Weight and Shipping Information
Net weight † 211 kg
(465 lb.)
236 kg
(520 lb.)
368 kg
(811.30 lb.)
358 kg
(789 lb.)
391 kg
(862.01 lb.)
Net weight †† 236 kg
(520 lb.)
241 kg
(531 lb.)
N/A
347 kg
(765 lb.)
N/A
Shipping weight † 233 kg
(514 lb.)
258 kg
(569 lb.)
383 kg
(844.37 lb.)
388 kg
(855 lb.)
418 kg
(921.53 lb.)
Shipping weight †† 283 kg
(624 lb.)
290 kg
(639.5 lb.)
N/A
467 kg
(1030 lb.)
N/A
Shipping volume 0.8 m
3
(22.5 ft. 3 )
0.9 m
3
(24.5 ft. 3 )
1.21 m
3
(42.83 ft. 3 )
1.3 m
3
(34.7 ft. 3 )
1.3 m
3
(45.98 ft. 3 )
Wash Cylinder Information
Cylinder diameter 530 mm
(20.9 in.)
530 mm
(20.9 in.)
680 mm
(26.77 in.)
650 mm
(25.6 in.)
680 mm
(26.77 in.)
Cylinder depth 345 mm
(13.6 in.)
440 mm
(17.3 in.)
400 mm
(15.75 in.)
500 mm
(19.7 in.)
500 mm
(19.69 in.)
Cylinder volume 76 l
(2.7 ft.
3
)
97 l
(3.43 ft.
3
)
145 l
(5.12 ft.
3
)
167 l
(5.9 ft.
3
)
181 l
(6.39 ft.
3
)
Perforation size 3 mm
(0.1 in.)
3 mm
(0.1 in.)
3 mm
(0.1 in.)
3 mm
(0.1 in.)
3 mm
(0.1 in.)
Door Opening Information
Door opening size 300 mm
(11.8 in.)
300 mm
(11.8 in.)
400 mm
(15.75 in.)
300 mm
(11.8 in.)
400 mm
(15.75 in.)
Height of door bottom above floor 279 mm
(11 in.)
279 mm
(11 in.)
472 mm
(18.58 in.)
395 mm
(15.6 in.)
472 mm
(18.58 in.)
