Basic Installation/Operation
9001014 24
Mechanical Installation
Frame Dimensions and Mounting Bolt
Location for 18, 25, 33, 35, 40, 55, 75,
100, 135, 165 and 200 Models
Figure 12
Figure 13
Figure 15
CFS479N
CFS478N
&)61
18 MODEL
660 mm
(26 in.)
560 mm
(22.05 in.)
670 mm
(26.38 in.)
55 mm
(2.17 in.)
486 mm
(19.13 in.)
87 mm
(3.43 in.)
55 mm
(2.17 in.)
87 mm
(3.43 in.)
CFS478N
660 mm
(26 in.)
660 mm
(25.98 in.)
87 mm
(3.43 in.)
55 mm
(2.17 in.)
770 mm
(30.31 in.)
87 mm
(3.43 in.)
486 mm
(19.13 in.)
55 mm
(2.17 in.)
25 MODEL
CFD541N
Figure 14
CFS480N
CFD541N
34 mm
(1.34 in.)
6
65 m
m
(
25.
18 in.
)
680 mm (26.77 in.) 50 mm
(1.97 in.)
73
3 m
m
(2
8.8
6 i
n
.)
50 mm
(1.97 in.)
780 mm (30.71 in.)
22 mm
(.87 in.)
33 MODEL
3
4 m
m
(1
.34
in
.)
CFS480N 35 MODEL
782 mm
(30.8 in.)
860 mm
(33.85 in.)
71 mm
(2.78 in.)
45 mm
(1.77 in.)
770 mm
(30.31 in.)
639 mm
(25.16 in.)
45 mm
(1.77 in.)
71 mm
(2.78 in.)
