Basic Installation/Operation
Figure 8
1 Fill and Supply Ventilation 7 Electrical Power Input
2 Cold Water Inlet (Required) 8 External Supply Signal Input
3 Hot Water Inlet (Required) 9 Drain Outlet
4 Cold Water Inlet (Required) 10 Reuse Drain Outlet (Optional)
5 Flushing Supply Dispenser 11 Steam Connection Input (Optional)
6 External Liquid Supply Inlets
&)61
CFD510N
CFS473N
CFD510N
1575 mm
(62 in.)
853 mm
(33.6 in.)
1532 mm
(60.3 in.)
1168 mm
(46 in.)
CFS473N
CFS474N
75 MODEL
229 mm
(9 in.)
488 mm
(19.2 in.)
94 mm
(3.7 in.)
175 mm
(6.9 in.)
170 mm
(6.7 in.)
104 mm
(4.1 in.)
1407 mm
(55.4 in.)
582 mm
(22.9 in.)
43 mm
(1.7 in.)
2 3 4
9
11
5
102 mm
(4 in.)
559 mm
(22 in.)
1060 mm
(41.73 in.)
1
7
8
104 mm
(4.1 in.)
10
246 mm
(9.7 in.)
6
1315 mm
(51.75 in.)
870 mm
(34.25 in.)
960 mm
(37.8 in.)
366 mm
(14.4 in.)
