Basic Installation/Operation

9001014

Machine Foundation

Thoroughness of detail must be stressed with all

foundation work to ensure a stable unit installation.

eliminating possibilities of excessive vibration during

extract.

The washer-extractor must be placed on a smooth

level surface so that the entire base of the machine is

supported and rests on the mounting surface.
The standard installation does not require anchoring

unless mandated by state or local codes.
Static and dynamic loads on the floor or foundation are

shown in Table 2.
Table 2 can be used as a reference when designing

floors and foundations.

Ensure that the machine is installed on a

level floor of sufficient strength and that

the recommended clearances for

inspection and maintenance are provided.

Never allow the inspection and

maintenance space to be blocked.

W488

CAUTION

Floor Load Data

Model

100

135

165

200

Kinetic Energy of
the Cylinder,
(N/m)

1386

1730

2736

3240

4105

6640

12404

18361

23257

29581

Dynamic Bottom
Load, (N/Hz)

700/16 750/16 1200/16 1200/16 1200/16 1700/15 2000/15 2960/13 3900/13 4960/13 6100/13

Table 2
