Basic Installation/Operation
9001014 10
(continued)
General Specifications
Model 55 75 100 135 165 200
Drive Train Information
Number of motors in drive train 1 1 1 1 1 1
Drive motor power 3 kW
(4 HP)
4 kW
(5.4 HP)
5.5 kW
(7.4 HP)
7.5 kW
(10 HP)
11.5 kW
(15 HP)
15 kW
(20 HP)
Cylinder Speeds
Wash/reverse speed 10-50 RPM 10-50 RPM 10-50 RPM 10-50 RPM 10-50 RPM 10-50 RPM
Distribution/drain speed 69 RPM 65 RPM 61 RPM 61 RPM 100 RPM 80 RPM
Extract speed 250-1000
RPM
250-1000
RPM
250-800
RPM
250-800
RPM
250-750
RPM
250-750
RPM
Centrifugal Force Data
Wash/reverse centrifugal force 0.04-1.05
Gs
0.05-1.19
Gs
0.06-1.37
Gs
0.06-1.37
Gs
0.06-1.52
Gs
0.06-1.52
Gs
Extract centrifugal force 26-418 Gs 30-475 Gs 34-350 Gs 34-350 Gs 34-344 Gs 34-342 Gs
Balance Detection
Vibration safety switch installed Standard Standard Standard Standard Standard Standard
Direct Steam Heating (Optional)
Steam inlet connection size 10 mm
(0.38 in.)
10 mm
(0.38 in.)
10 mm
(0.38 in.)
10 mm
(0.38 in.)
10 mm
(0.38 in.)
19 mm
(0.75 in.)
Number of steam inlets 1 1 1 1 1 1
Electrical Heating (Optional)
Total electrical heating capacity 18 kW 18 kW 27 kW 27 kW N/A 36 kW
Electrical heating elements 6 6 9 9 N/A 9
Electrical heat element size 3 kW 3 kW 3 kW 3 kW N/A 4 kW
