Basic Installation/Operation
Figure 20
Figure 21
CFS484N
CFS484N
135 MODEL
1200 mm
(47.24 in.)
1270 mm
(50 in.)
1185 mm
(46.65 in.)
80 mm
(3.15 in.)
1040 mm
(40.94 in.)
80 mm
(3.15 in.)
42,5 mm
(1.67 in.)
42,5 mm
(1.67 in.)
165 MODEL
1300 mm
(51.2 in.)
1251 mm
(49.25 in.)
80 mm
(3.15 in.)
80 mm
(3.15 in.)
1185 mm
(46.7 in.)
1140 mm
(44.9 in.)
33 mm
(1.3 in.)
33 mm
(1.3 in.)
CFd536N
Figure 22
CFD536N
44 mm
(1.73 in.)
1300 mm (51.18 in.)
61 mm
(3.19 in.)
44 mm
(1.73 in.)
61 mm
(3.19 in.))
1138 mm (44.8 in.)
13
00
m
m
(
5
1.
18
in
.)
200 MODEL
11
3
5 m
m
(44
.8
in
.)
