ASUS TUSL2 User’s Manual 67
4. BIOS SETUP
4. BIOS SETUP
I/O Device Config
UART2 Use [COM Port]
When IR is enabled, this field activates the onboard standard infrared fea-
ture and sets the second serial UART to support the infrared module
connector on the motherboard. If your system already has a second serial
port connected to the onboard COM2 connector, it will no longer work if
you enable the infrared feature. To support a Smart Card Reader, select
Card Reader. Configuration options: [COM Port] [IR] [Card Read Read]
Onboard Parallel Port [378H/IRQ7]
This field sets the address of the onboard parallel port connector. If you
disable this feature, Parallel Port Mode and ECP DMA Select configura-
tions will not be available. Configuration options: [Disabled] [378H/IRQ7]
[278H/IRQ5]
Parallel Port Mode [ECP+EPP]
This field allows you to set the operation mode of the parallel port. [Nor-
mal] allows normal-speed operation but in one direction only; [EPP] al-
lows bidirectional parallel port operation; [ECP] allows the parallel port to
operate in bidirectional DMA mode; [ECP+EPP] allows normal speed op-
eration in a two-way mode. Configuration options: [Normal] [EPP] [ECP]
[ECP+EPP]
ECP DMA Select [3]
This field allows you to configure the parallel port DMA channel for the
selected ECP mode. This selection is available only if you select [ECP] or
[ECP+EPP] in Parallel Port Mode above. Configuration options: [1] [3]
Onboard CIR I/O [Disabled]
This field sets the address of the onboard Consumer IR connector. Con-
figuration options: [Disabled] [2E0-2E8H] [3E0-3E8H]
