ASUS TUSL2 User’s Manual
3. HARDWARE SETUP
16
Layout Contents 3. H/W SETUP
18) ACHA p.40 Chassis Intrusion Connector (2 pins)
19) WOL_CON p.41 Wake-On-LAN Connector (3 pins)
20) WOR_CON p.41 Wake-On-Ring Connector (2 pins)
21) LCDTV p.42 LCD-TV Headers (18-1 pins/18 pins)
22) USB23 p.42 USB Headers (5-1 pins, Two 10-1 pins)
23) SMARTCON p.42 ASUS SmartCard Connector (10-1 pin)
24) ATXPWR p.43 ATX Power Supply Connector (20 pins)
25) JTPWR p.43 Power Supply Thermal Sensor Connector (2 pins)
26) PWRLED (PANEL) p.44 System Power LED Lead (3-1 pins)
27) KEYLOCK (PANEL) p.44 Keyboard Lock Switch Lead (2 pins)
28) SPEAKER (PANEL) p.44 System Warning Speaker Connector (4 pins)
29) MSG.LED (PANEL) p.44 System Message LED (2 pins)
30) SMI (PANEL) p.44 System Management Interrupt Switch Lead (2 pins)
31) PWRSW (PANEL) p.44 ATX Power / Soft-Off Switch Lead (2 pins)
32) RESET (PANEL) p.44 Reset Switch Lead (2 pins)
