ASUS TUSL2 User’s Manual

3. HARDWARE SETUP

Expansion Cards

3. H/W SETUP

3.7.3 Communication and Networking Riser (CNR) Slot

This connector supports specially designed network, audio, or modem riser cards.
Main processing is done through software and controlled by the motherboard’s sys-
tem chipset. This provides upgradeable network, audio, and/or modem solutions at
an incredibly low cost.

NOTE: A CNR is not included with this motherboard.

TUSL2

COM1

TUSL2 Communication
& Networking Riser Connector
