WebShare 144WN
A02-RA144-W300N Pag. 71
Rule
You can set 16 different QoS rules. Each QoS rule has its detail setting conditions
like: 802.1p,application, DSCP, IP, MAC, Protocol, TOS, VLAN…etc, you can
modify the default value to any new one you wish. Please notice that only when
the packet fulfill every detail setting conditions here, then this packet will be
remarked as the priority queue of each rule. The non-selected setting part will be
treated as “don’t care” and the system will not handle this setting part. If the
original packet does not have 802.1q tagged header, system will not add header
for this packet even the detail setting condition has adding 802.1p priority ability.
Field Meaning
Rule Index
Select 16 different rules, each rule’s detail can be set and
saved.
Active Select QoS is activated or deactivated.
Application Select 11 different applications: IGMP, SIP, H.323, MGCP,
SNMP, DNS, DHCP, RIP, RSTP, RTCP, RTP.
Physical Ports Once you select the application, the associated ports will be
displayed.
Destination MAC Set the Ethernet MAC value that you want to filter in
destination side.
IP (Destination) Set the IP address value that you want to filter in destination
side.
Mask
(Destination) Set the subnet mask value that you want to filter in
destination side.
Port Range Set the port range value that you want to filter in destination
side.
Source MAC Set the Ethernet MAC value that you want to filter in source
side.
IP (Source) Set the IP address value that you want to filter in source
side.
Mask (Source) Set the subnet mask value that you want to filter in source
side.
Port Range Set the port range value that you want to filter in source
side.
Protocol ID Set the protocol ID type that you want to filter.
VLAN ID Range Set the Vlan value that you want to filter.
IPP/DS Field Select IP QoS format.
IP Precedence
Range: Select the IP precedence range.
Type of Service: Select 5 different type of service.
DSCP Range Set the DSCP value that you want to filter.
802.1p Set the remarked new 802.1p priority value on the packet
that fulfill every detail setting condition of each rule.
