WebShare 144WN
A02-RA144-W300N Pag. 61
Direction Select the
access to the Internet (“Outgoing”) or from
the Internet (“Incoming”).or Both
IP FILTER RULE EDITING:
Field Meaning
Ip Filter Rule
Index
This is item number
Active Select Yes from the drop down list box to enable IP filter
rule
Source IP
Address
The source IP address or range of packets to be
monitored
Subnet Mask It is the destination IP addresses based on above
destination subnet IP
Source Port
Number
This Port or Port Ranges defines the port allowed to be
used by the Remote/WAN to connect to the application.
Default is set from range 0 ~ 65535. It is recommended
that this option be configured by an advanced user
Destination IP
Address
This is the destination subnet IP address
Subnet Mask It is the destination IP addresses based on above
destination subnet IP
Protocol It is the packet protocol type used by the application,
select either TCP or UDP or ICMP
Rule Unmatched Select action for the traffic unmatching current rule;
Forward to leave it pass through, and NEXT to check it by
the next rule
IP FILTER LIST:
Field Meaning
# Item number
Active Whether the connection is currently activ
Source IP Mask The source IP address or range of packets to be
monitored
Destination IP
Mask
This is the destination subnet IP address
Source port This Port or Port Ranges defines the port allowed to be
used by the Remote/WAN to connect to the application.
Default is set from range
0 ~ 65535. It is recommended
that this option be configured by an advanced user
Destination Port This is the Port or Port Ranges that defines the application
