WebShare 144WN
A02-RA144-W300N Pag. 4
1.4 WebShare Wireless N Router ADSL2+ Application
Follow the followings steps to cabling the device:

Connect WAN Port to the telephone line throught RJ-11 cable (contained in
package).

WebShare Wireless N ADSL2+ Router can be connect in the following
configuration:

Directly at 4 PC, throught CAT5 cables (one is contained in
package)

To an Hub/Switch throught UPLINK Port thought CAT 5 cable
(contained in package).

Connect AC-DC Adapter on AC and on device (POWER jack) in the reat r of
the product.
