Atlantis Land A02-RA144-W300N - Manual (Page 50)

WebShare 144WN
A02-RA144-W300N Pag. 40
wireless clients have exactly the SSID as the device, in order to
get connected to your network.
WMM In order to increase the performance of Multimedia data, please
select
Enable.
WPS Select Yes in order to use WPS.
WPS Settings
Label Description
WPS State Displays whether the WPS is configured or unconfigured .
WPS Mode Select the mode which to start WPS, choose between PIN Code
or PBC (Push Button). Selecting Pin Code mode will require
you to know the enrollee PIN code.
SSSID Type in the Service Set Identifier name, it is the unique name of
a wireless access point (AP) to be distinguished from another.
Authentication
Type To prevent unauthorized wireless stations from accessing data
transmitted over the network, the router offers highly secure
data encryption, known as WEP.&WPA. If you require high
security for transmissions, there are two alternatives to select
from: 64-bit WEP and 128-bit WEP. WEP 128 will offer
increased security over WEP 64.
You can disable or enable with WPA or WEP for protecting
wireless network. The default type of wireless is disabled and to
allow all wireless computers to communicate with the access
points without any data encryption.
The range of radio frequencies used by IEEE 802.11g wireless
devices is called a “channel”. Channels available depend on your
geographical area. You may have a choice of channels (for your
region) so you should use a different channel than an adjacent AP
(access point) to reduce interference. Interference occurs when
radio signals from different access points overlap causing
interference and degrading performance.
Adjacent channels partially overlap however. To avoid interference
due to overlap, your AP should be on a channel at least five
channels away from a channel that an adjacent AP is using. For
example, if your region has 11 channels and an adjacent AP is using
channel 1, then you need to select a channel between 6 or 11.
