Getting started

5

Telephone installation

Telephone base installation

Install the mounting bracket for tabletop use.

option 1: Insert the tabs into slots

a

and

b

to install your telephone in

a low tabletop position. Press the flexible tabs

A

and

B

on the mounting

bracket until it clicks into place.

1.

A

B

A

B

c

option 1: Low tabletop position

option 2: Rotate the mounting bracket 180

degrees. Insert the tabs into slots

c

and

d

to install your telephone in a high tabletop position. Press the

flexible tabs

A

and

B

on the mounting bracket until it clicks into place.

A

A

option 2: high tabletop position
