IQ 310 T1 NETWORK INTERFACE MODULE (NIM)
P/N 1202802L1
For more detailed documentation, visit us online at
www.adtran.com
Quick Start Guide, 61202802L1-13A, March 2004
Technical Support 1-888-4ADTRAN (1-888-423-8726)
Copyright
© 2004 ADTRAN, All Rights Reserved
T1 N
ETWORK
(RJ-48C) C
ONNECTION
P
INOUT
Pin
Name
Description
1
R1
Receive data from the network
2
T1
Receive data from the network
3
—
UNUSED
4
R
Transmit data toward the network
5
T
Transmit data toward the network
6-8
—
UNUSED
