INTRODUCTION
The manageable 14-port HomePNA Switch
The manageable 14-port HomePNA Switch is a device utilizing the existing telephone
wiring within a building to deliver data and does not interrupt regular voice services.
Data and voice run simultaneously on the same pair of wire without any rewiring. It is
suitable for hotel/motel, multi-tenant apartment, multi-tenant commercial, multi-tenant
student dorm, campus and local loop. This switch supports a concentrator mode, where
each of the ports is dedicated to directly communicate with the Uplink/downlink ports.
This mode ensures that data from any of ports 1-14 cannot be directly seen by another port.
This feature, therefore, provides data privacy to subscribers.
The manageable 14-port HomePNA Switch is designed to eliminate unnecessary
network traffic, and relieve congestion by delivering dedicated bandwidth for each of the
ports. Able to begin operating after power-up, the switch will learn addresses
automatically, and begin forwarding packets at full wire-speed to any of the outputs.
Additionally, this switch comes with the full network management functions such as
SNMP, Web-browser, Telnet, Windows GUI tool and Local Console management.
Moreover, the switch can be operated stand-alone or can be cascaded to stack up with
multiple units to provide low cost network solutions.
Features
IEEE802.3 compliant for 10BASE-T,
IEEE802.3u for 100BASE-TX
HomePNA specification 1.1 compliant
14*1Mbps home networking ports supported
2*10/100M Fast Ethernet port supported and auto-MDI-X function supported
2*RJ-11 bypass connectors for each 1Mbps home networking port
Store-and-forward architecture filters
VLAN group supported
Rich diagnostic LED indicators
Rack-mount-sized design
Ethernet port for uplink connection
512KB system buffer memory supported
8K MAC address table supported
Internal universal switching power supply (90~ 240V)
SNMP management agent supported
Web management supported
Windows GUI configuration/management program supported
Local console management and Telnet management supported
