Sony PCG-GRS100 - Manual (Page 164)

VAIO Computer Quick Start
164
5 Align the connector on the bottom of the computer with the port replicator
connector, and push the computer down until it clicks into place.
6 Turn on the computer.
To disconnect a port replicator
1 Close any active programs to prevent data loss.
2 Disconnect all active peripheral (attached) devices.
3 Pull the release levers on each side of the port replicator to release the
computer from the port replicator.
4 Lift the computer away from the port replicator.
Connecting a Port Replicator
✍
When attaching your computer to the port replicator, do not attempt to insert or
remove the battery. Lifting and turning the computer with an attached port replicator
could cause a temporary loss of power.
Disconnecting a Port Replicator
Port replicator
Computer
Release levers on
both sides of
port replicator
