Basic Operations
8 EN
Recording on a Tape
See page 5 for hookup
information.
Window side up
2
5
6 3 8
7 4
MARGIN
OPEN/CLOSE
RESET
RESET MODE
ENTER MENU
REW FF
SELECT DATA
AMS INPUT
ID
PHONES SBM ID MODE REC MODE
REC REC MUTING PAUSE PLAY STOP
PHONE LEVEL
REC LEVEL
RENUMBER REHEARSAL AUTO
WRITE ERASE
g
6
5
4 6
0
3 7
2 8
1 9
10
MAX MIN
ON 48 kHz
44.1kHz
LONG
START
STOP
END
STANDARD
OFF
ANALOG OPT
POWER
COAXIAL
=
p P R r ”
+ 0 ) CH-1 (L) CH-2 (R)
Insert the cassette
beyond the silver
bar.
Do not close the
cassette holder
without pressing
OPEN/CLOSE
6.
1 Turn on the amplifier and play the program source you want
to record.
2 Press POWER.
3 Press OPEN/CLOSE 6 and insert a cassette.
6
OPEN/CLOSE
b b
6
OPEN/CLOSE
4 Set INPUT to the corresponding input connector.
To record through Set INPUT to
ANALOG (LINE) IN ANALOG
DIGITAL OPTICAL IN OPT
DIGITAL COAXIAL IN COAXIAL
z
You can monitor the input
signal (Source Monitor
function)
1 Do steps 1 and 2 on this
page.
2 Skip steps 3 and 5, and do
steps 4 and 6.
When you press the REC
r
button, “NO TAPE” and
“SOURCE” appear in the
display and you can
monitor the program source
connected to the selected
input connector.
